Advanced x86:

Introduction to BIOS & SMM

Welcome    Why?    Training    Games    ChangeBlog    External Resources    Submit Content



Creator:      (2014) John Butterworth @jwbutterworth3

Instructor:  (2014) John Butterworth

                    (2014-current) Xeno Kovah  @xenokovah


License:    Creative Commons: Attribution, Share-Alike

(http://creativecommons.org/licenses/by-sa/3.0/)


Class Prerequisites: While it is possible to do OK in this class without this background knowledge, ideally you should have taken Intro x86 (for knowledge of assembly), Introduction to Reverse Engineering Software (for knowledge of reversing, for application to BIOS), Intermediate x86 (for knowledge of GDT, and port IO), and Life of Binaries (for knowledge of the PE format), or equivalent knowledge.


Lab Requirements: Windows >= 7


Class Textbooks: None


Recommended Class Duration: 2-3 days


Instructor Available to Teach In-Person Classes: Yes


Author Comments:


PC BIOS/UEFI firmware is usually “out of sight, out of mind”. But this just means it’s a place where sophisticated attackers can live unseen and unfettered. This class shares information about PC firmware security that was hard-won over years of focused research into firmware vulnerabilities.


We will cover why the BIOS is critical to the security of the platform. This course will also show you what capabilities and opportunities are provided to an attacker when BIOSes are not properly secured. We will also provide you tools for performing vulnerability analysis on firmware, as well as firmware forensics. This class will take people with existing reverse engineering skills and teach them to analyze UEFI firmware. This can be used either for vulnerability hunting, or to analyze suspected implants found in a BIOS, without having to rely on anyone else.


Learning Objectives

* Understand the similarities and differences between the UEFI and legacy BIOS

* Understand the BIOS/UEFI boot environments and how they interact with the platform architecture

* How the BIOS/UEFI should configure the system to maximize platform security, and how attackers have bypassed these security mechanisms

* How System Management Mode (SMM) is instantiated and must be protected

* How SMM may be used to provide added layers of platform security

* How the BIOS flash chip should be locked down, and what kind of attacks can be done when it is not

* Learn how to Reverse Engineer UEFI modules

* To teach you “how to fish” so you can take your newly-acquired knowledge to perform further security research in this area




Latest Class Materials (Xeno Kovah - 10-14-2015)


(All 828 slides (pptx & pdf))


Day 1

Introduction (11 slides)
Motivation (27 slides)
Tools (29 slides)
Chipset Architecture (65 slides)
Boot Process (8 slides)
Input/Output (28 slides)
PCI (54 slides)
PCI {Option/Expansion} ROMs (21 slides)
System Management Mode (SMM) (26 slides)
SMRAM (System Management RAM) (45 slides)
SMM & Caching Attacks (14 slides)
More Fun with SMM (48 slides)
SMM Conclusion (4 slides)
(Optional) Memory Map (6 slides)
(Optional) Reset Vector (48 slides)
(Optional) SMI Suppression (18 slides)


Day 2

SPI Flash Programming (42 slides)
SPI Flash (28 slides)
Flash Descriptor (30 slides)
SPI Flash Protection Mechanisms (38 slides)
Unified Extensible Firmware Interface (UEFI) (55 slides)
UEFI Reverse Engineering (77 slides)
UEFI SecureBoot (35 slides)
Trusted Computing Technologies (59 slides)
Conclusion (11 slides)



Original Public Released Class Materials (John Butterworth - 2014)


(All 657 slides)



Revision History:


10-14-2015 - Initial class content (John’s version & Xeno’s version) uploaded


If you have used and modified this material, we would appreciate it if you submit your modified version for publishing here, so that all versions can benefit from your changes.
